Abb S900,Ci920As,Ai910S,Ao910S,Ip920,Dx910S,Do910S Terminal Unit Tu921S
Abb Ab
Abb Automation
Termination Unit
S900
Tu921s
Df 1315
280190016
Hw: 03.00
Ptb 00 Atex 2156 U
Ii 2 (1) G Eex E Ib [ia] Iic T4
Ta 60c
Communication Interface
Cipba-ex
No: Ci920as
Order No: 3bdh000690r1
Df 1317
397800085
Hw: 02.00
Sw: 2.1.0.0
Profibus-dp-is-connection
Uo/voc: 3,6v
Io/isc: 125 Ma
Po: 112,5 Mw
Ui/vic: 4,2 V
Ta 70c
Ptb Ii Atex 2001
Ii 2 G Ex Ib Iic T4
No/nr: 0044
Analog Input
Ai4-ex
No: Ai910s
Order No: 3kde175511l9100
Df 1320
335800037
Hw: 02.02
Sw: 1.90
Hr: 17010803d
Output:
Uo/voc: 22,1 V
Co/ca: 65 Nf
Io/isc: 93 Ma
Lo/la: 0.5 Mh
Po: 640 Mw
Ta Less Than 60c
Ptb 00 Atex 2058 X
Ii 2 (Ig/d) G Ex [ia] Ib Iic T4
Analog Output
Ao4-ex
No: Ao910s
Order No: 3kde175531l9100
Df 1325
9544420046
Hw: 02.03
Sw: 1.91
Hr: 17005502a
Ta Less Than 70c
Characteristic: Trapezoidal
Ci Less Than=1.1 Nf
Li Less Than=0.22mh
Ptb 02 Atex 2029
Ii 2 (I) G Ex Ib [ia Ga] Iic T4 Gb
And
Ii (I) D [ex Ia Iiic Da]
No: Ip920
Nr: 0102
Digital In/out
Dio8-ex
No: Dx910s
Order No: 3kde175311l9100
Df 1327
315800217
Hw: 02.00
Sw: 2.0.0.0
Hr: 170439018
Output:
Uo/voc: 9,6 V
Co/ca: 1,1 f
Io/isc: 44 Ma
Lo/la: 1 Mh
Po: 106 Mw
Ptb 00 Atex 2180
Ii 2 (I) G Ex Ib [ia] Iic T4
And Ii (I) D [ex Ia Iiic]
Digital Output
Do4-ex
No: Do910s
Order No: 3kde175321l9100
Df 1429
2085970160
Output:
Uo: 25 V
Lo/co: 0,2 Mh2 Mh/-0,1 Mh/110 Nf
Io: 80 Ma
Po: 750 Mw
Characteristic: Angular
Knee-point Volt.: Ue= 18,2/13 V
Knee-point Curr.: Ie= 41,2/53,4 Ma
Uo: 19 V
Lo/co: 2mh/-
1 Mh/130 Nf
0,5 Mh/140 Nf
0,2 Mh/170 Nf
Io: 100 Ma
Po: 710 Mw
Ptb 12 Atex 2008
Ii 2 (I) G Ex Ib [ia Ga] Iic T4 Gb
And Ii (I) D [ex Ia Iiic Da]
Made In Germany
Weight: 5.040 Kg
